Description
Features Include:
- Version A according to EN 50041 (steel roller ø 18 mm)
- Switching principle: Snap-action switching contact
- Rated impulse withstand voltage Uimp: 1.5 kV
- Rated insulation voltage Ui: 50 V
- Short circuit protection according to IEC 60269-1: 4A gG
- Switching current: min. at DC 24V 1 mA
- Thermal rated current Ith: 4 A
- Utilization category: DC-13 4A 24V | AC-15 4A 50V
- Actuating element: Slide bearing metal Lever arm
- Actuating force min.: 15 N
- Ambient temperature: -25 - +80 °C
- Approach speed: 0.1 - 60 m/min
- Connection: 1 x Plug connector SR11
- Degree of protection: IP65
- Installation orientation: any
- Material: Housing Anodized die-cast alloy | Contact Silver alloy, gold flashed
- Number of door position positively driven contacts: 2
- Number of NO contacts: 2
