090146

090146

Alt: 90146, NZ2HS-2131

$184.20

Single Plunger, NZ2HS-2131

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.

Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Features Include:

  • Version A according to EN 50041 (steel roller ø 18 mm)
  • Switching principle: Snap-action switching contact
  • Rated impulse withstand voltage Uimp: 1.5 kV
  • Rated insulation voltage Ui: 50 V
  • Short circuit protection according to IEC 60269-1: 4A gG
  • Switching current: min. at DC 24V 1 mA
  • Thermal rated current Ith: 4 A
  • Utilization category: AC-15 4A 50V | DC-13 4A 24V
  • Actuating element: Slide bearing metal Lever arm
  • Actuating force min.: 15 N
  • Ambient temperature: -25 - +80 °C
  • Approach speed: 0.1 - 60 m/min
  • Connection: 1 x Plug connector SR11
  • Degree of protection: IP65
  • Installation orientation: any
  • Material: Housing Anodized die-cast alloy | Contact Silver alloy, gold flashed
  • Number of door position positively driven contacts: 3
  • Number of NO contacts: 1
