105839

105839

Alt: NZ2HB-511SVM5L060GEC2273

$196.41

Single Plunger, NZ2HB-511SVM5L060GEC2273

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.

Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Features Include:

  • Version A according to EN 50041 (plastic roller ø 18 mm)
  • Display module: AC/DC 12 - 60 - 60 V LED yellow
  • Rated impulse withstand voltage Uimp: 1.5 kV
  • Rated insulation voltage Ui: 50 V
  • Short circuit protection according to IEC 60269-1: 4A gG
  • Switching current: min. at DC 24V 10 mA
  • Thermal rated current Ith: 4 A
  • Utilization category: AC-15 4A 30V | DC-13 4A 24V
  • Actuating element: Slide bearing plastic Lever arm
  • Actuating force min.: 15 N
  • Ambient temperature: -25 - +80 °C
  • Approach speed: 0.1 - 300 m/min
  • Connection: 1 x Plug connector M12
  • Degree of protection: IP67
  • Installation orientation: any
  • Contact: Silver alloy, gold flashed
  • Housing: Anodized die-cast alloy
  • Mechanical life: 30 x 10⁶
  • Number of door position positively driven contacts: 1
  • Number of NO contacts: 1
  • Switching principle: Slow-action switching contact
