091312

091312

Alt: 91312, NZ1HS-511-MC1833

$121.51

Single Plunger, NZ1HS-511-MC1833

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.

Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Features Include:

  • Version A according to EN 50041 (steel roller ø 18 mm)
  • With grooved ball bearing
  • Switching principle: Snap-action switching contact
  • Connection cross-section: 0.34 - 1.5 mm²
  • Rated impulse withstand voltage Uimp: 2.5 kV
  • Rated insulation voltage Ui: 250 V
  • Short circuit protection according to IEC 60269-1: 6A gG
  • Switching current: min. at DC 24V 10 mA
  • Thermal rated current Ith: 6 A
  • Utilization category: AC-12 10A 230V | AC-15 6A 230V | DC-13 6A 24V
  • Actuating element: Slide bearing metal Lever arm
  • Actuating force min.: 15 N
  • Ambient temperature: -25 - +80 °C
  • Approach speed: 0.1 - 60 m/min
  • Connection: 1 x M20 x 1.5
  • Degree of protection: IP67
  • Installation orientation: any
  • Material: Housing Anodized die-cast alloy | Contact Silver alloy, gold flashed
  • Number of door position positively driven contacts: 1
  • Number of NO contacts: 1
