$9.77
Description
Features Include:
- Connection cross-section: max. 1.5 mm²
- Rated impulse withstand voltage Uimp: 2.5 kV
- Rated insulation voltage Ui: 250 V
- Switching current (Min. at DC 5V): 1 mA
- Thermal rated current Ith: 10 A
- Utilization category: DC-13 3A 24V, AC-15 4A 230V
- Actuating element: Chisel plunger
- Actuating force: 15 - 20 N
- Ambient temperature: -25 - +70 °C
- Approach speed: 0.01 - 20 m/min
- Connection: 1 x M12 x 1.5
- Degree of protection: IP67
- Installation orientation: any
- Material: Housing Anodized die-cast alloy, Contact Silver alloy, gold flashed
- Mechanical life: 10 x 10⁶
- Number of door position positively driven contacts: 1
- Switching principle: Slow-action switching contact
