Pizzato
VN NG-F31
Actuator for NG Series with High Coding Level, Switch Recognizes One Single Type F31 Actuator
$113.22
NG 2D5D411A-F31
Alt: NG2D5D411A-F31
$973.29
RFID Safety Switch with Solenoid, Locked Actuator with De-Energized Solenoid with Auxiliary Key Release, NG Series, High Level Coded Actuator, 2 Safety Inputs/2 Safety Outputs, Safety Locking Switch with RFID Technology
- Weight:
- 3.85 LBS
- Minimum Purchase:
- 1 unit
Description
Our Pizzato NG series offers a safety locking switch with RFID technology.
Features Include:
- Actuator holding force: 9750N
- Models with up to IP67 and IP69K protection
- PL e offers series connection of up to 32 devices
- Optional integrated control devices
- Metal housing (NS series offers plastic housing)
Actuator options:
- VN NG F30 - low level code actuator, the switch recognizes any type F30 actuator
- VN NG F31 - high level coded actuator, the switch recognizes one single type F31 actuator
Features Include:
- Protection degree: IP67 according to EN 60529 and IP69K according to ISO 20653
- Cover configuration: No device
- Housing: Metal housing, three threaded M20x1,5 conduit entries.
- Head: Rotating head with lock auxiliary release device
- Working method: D working method, locked actuator with de-energized solenoid
- Safety output activation OS: Activation mode 1: safety outputs active with actuator inserted and locked
- Actuator: Complete with actuator with high coding level VN NG-F31
- Type of connection: Without connector
- Inputs and outputs:
- 2 safety inputs IS1-IS2,
- 2 safety outputs OS1-OS2,
- 1 signaling output O3: actuator inserted,
- 1 signaling output O4: actuator locked,
- I4 or IE1-IE2 inputs for solenoid activation,
- 1 input I3: actuator programming / reset
Technical Information:
