02036OT3E254JM-W40
Alt: 14483518, Replaced 02036OT3E254JM (11080333)
$1,580.25
Motor, 20hp (15kW), 3600rpm, 2-Pole, Three Phase, 230/460//380V, 60//50Hz, 254JM Frame, JM Pump NEMA Premium Efficiency, IC01-ODP Enclosure, Footed/C Flange, F-1 Mounting, Left Position Terminal Box, IP23
- Weight:
- 237.00 LBS
- Minimum Purchase:
- 1 unit
Description
WEG is a global manufacturer of electric motors, variable frequency drives, soft starters and controls. The controls line includes contactors, starters, circuit breakers and much more.
WEG Electric Corp. USA, located in Duluth, GA, has a number of distribution centers including one right here in the Chicago area.
Features Include:
- Standard: NEMA MG-1
- Frame: 254JM
- Frequency: 60/50 Hz
- Voltage: 230/460/380 V
- Rated current: 48.6/24.3 A
- No load current: 16.8/8.40 A
- Rated torque: 29.7 ft.lb
- Number of poles: 2
- Degree of Protection: IP23
- Synchronous speed: 3600 rpm
- Output rating: 20 HP
- Starting Method Direct On Line
- Mounting: Foot-mounted
- Flange: C
- Mounting: F-1
- Terminal box¹: Left position
- Enclosure: IC01 - ODP
Technical Information:
- Weg 02036OT3E254JM-W40 W40 JM Pump Motor Technical Data
- Weg W40 Three-Phase Electric Open Drip Proof Brochure
- Weg W40 Drip Cover Assembly Procedure
- Weg Installation, Operation and Maintenance Manual of Electric Motors
- Weg Installation, Operation and Maintenance Manual of Low and High Voltage Electric Motors
- Weg Part Number Configuration
- Weg Specification of Electric Motors
- Weg Standard Product Catalog
