8830000353
Alt: S35 RHT-PROBE, This is the Recommended Replacement for 8830000060
$76.00
S35 RHT-PROBE Temperature & Humidity Sensor for N32X and XS, 3m Cable Length
- Minimum Purchase:
- 1 unit
Description
Features Include:
- One control outlet (Output1) with a SPDT relay, 1HP (16A resistive) /250Vac and another control outlet (Output2) with a SPST relay, 3A (5A resistive)/250 VAC
- 3½-digit LED Display
- Sensor offset adjustment
- Adjustable hysteresis
- Different temporization can be set to each output
- Third output can be set as cyclic timer
- Configurable set point minimum and maximum limits
- Program retention during power failures
- Configurable password equipment protection
- Silicone keys with excellent durability
- Front-panel with IP65 protection
- Humidity and temperature measuring ranges (see figure): - RH: 0 to 100% of relative humidity, - T: -20 to 100 °C
- Measurement resolution: - RH: 1% in the whole range, - T: 0.1 °C from -19.9 to 100.0 °C
- Power supply: 100 to 240 VAC /dc ±10%
- Frequency: 50~60 Hz
- Consumption: 5 VA
- Dimensions: Humidistat: 75 x 33 x 75 mm / Sensor: 125 x 13.7 mm (length x diameter) / Sensor cable: 3 meters / Panel cutout: 70 x 29 mm
Technical Information:
- Novus N323 RHT Series Humidity and Temperature Controller Flyer
- Novus N323 RHT Series Humidity and Temperature Operating Manual
- Novus N323 RHT Modbus Protocol Technical Data
- Novus RHT-Probe Humidity and Temperature Controller User Manual
- Novus Electronic Thermostats Brochure
- Novus Electronic Thermostats Selection Guide
