608.3000.289
Alt: IN65-U1Z M12
$54.51
Switch Body Only w/M12, 1NC/1NO, Slow Action w/Contact Block Only (No Actuator)
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Insulation Voltage: 250 V
- Rated Impulse Withstand Voltage: 2.5 kV
- Rated Operational Voltage: 240 V AC
- Rated Supply Frequency AC: 50/60 Hz
- Conv. Thermal Current: 4 A
- Minimum Current: 1 mA
- Enclosure: Thermoplastic, glass fiber reinforced (UL 94-V0)
- Connection: Connector M12x1, A-coded
- Standard switches conforming to DIN EN 50047
- Modular design
- High reliability at low currents (1 mA)
- Tool-free turning and changing of actuator
- Metal actuator locking
- Metal mounting clip
- Protection class IP66 and IP67
- Hinged snap-on cover
