Product image is representative only, please verify specifications.
6075685094
Alt: 607.5685.094, SRF-4/1/1-E-U
$256.64
Safety Cable Pull Switches
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Bernstein is a German manufacturer of industrial safety and enclosure technology and are well known for a wide range of sensors, switches, enclosures and operating terminals.
If you do not see the part number you are looking for, please Contact Us, we can find what you need!
Features Include:
Electrical data
- Rated operational voltage Ue: 24 V
- Output current of the safety outputs Ie: 100 mA
- Output current of the message output Ie: 10 mA
Mechanical data
- Housing: PA66 + PA6, red, self-extinguishing
- Connection cable: PUR
- Mounting holes: Ø 4,5 (for M4 screws)
- Displays: 1 × LED red/green operating status, 1 × LED yellow actuation status
- Ambient temperature: -25 °C to +70 °C
- Protection class: IP69
Safety data sheet
- PL e / Kat. 4 (according to EN ISO 13849-1)
- SIL CL 3 (according to DIN EN 62061)
- PFHD = 6 × 10-9 1/h
- Mission time: 20 years
- Switching distance:
- Rated operating distance Sn: 13 mm
- Assured switching distance – On Sao: 10 mm
- Assured switching distance – Off Sar: 25 mm
- Hysteresis: 2 mm
- Switch-off delay ta: max. 100 ms
- Ready delay tv: max. 2 s
