WM20AV53H
Alt: Manufacturer Minimum Order 3 Pieces, SMART MODULAR POWER ANALYZER 400V-5A HIGH PS
$440.00
Modular Power Analyzer for 3 Phase Systems, Optional I/O and Communication Modules (Modbus RTU, Modbus TCP/IP, BACnet, Profibus), Optical Port, Auxiliary Power Supply. 220 to 400 V L-N, 380 to 690 V L-L. CT input: 1 (2) A
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 3 units
Description
Carlo Gavazzi is a worldwide leader that designs and manufactures sensors, solid state relays and safety devices as well as monitoring relays, timers and energy management systems.
Carlo Gavazzi was founded in Milan, Italy in 1931 and the U.S. headquarters is located in Buffalo Grove, Illinois.
Technical Features Include:
- Material Front: ABS, self-extinguishing V-0 (UL 94)
- Back and accessory modules: PA66, self-extinguishing V-0 (UL 94)
- Protection grade Front: IP65 NEMA 4x NEMA 12
- Terminal Protection Rating: IP20
- Terminals Type: Detachable / Section: 2.5 mm2 maximum / Torque: 0.5 Nm
- Insulation: Double electrical insulation on areas accessible to the user.
General Main Features:
- System and phase variables (4 x 3 digits): V L-L, V L-N, A, W/var/VA, PF, Hz
- Active and reactive imported and exported energy meters (10 digits)
- Calculate the average and maximum system and phase power values
- Calculate current and voltage THD (total harmonic distortions) up to the 32nd harmonic
- Calculate load operating hours
- Rotating pages function
- Auxiliary power supply
- Two virtual alarms
- Backlit LCD display and touch keypad
- Optical port
- Detachable terminals
- Sealable terminal caps
- Configuration via keypad or UCS configuration software
- Filter to stabilize displayed measurements
