P1-01530-LFUF
Alt: SJ-P1 Series
$2,532.53
VFD, 40hp, 3 Phase, 200/240V, 121/140/153 A, ND/LD/VLD, High Performance Vector Drive
- Weight:
- 49.00 LBS
- Minimum Purchase:
- 1 unit
Description
The new SJ-P1 can easily handle heavy loads that require high starting torque at low speed. This series is also great for high speed rotation applications because of a 590Hz maximum operating frequency.
- VLD = very light load (110% 60 seconds, 120% 3 seconds)
- LD = light load (120% 60 seconds, 150% 3 seconds)
- ND = normal load (150% 60 seconds, 200% 3 seconds)
The built-in automatic speed adjustment reduces the risk of issues with trips during acceleration and deceleration. You can control both induction and permanent magnet motors and there are easily accessible slide-in cassettes to enhance integration and performance.
The SJ-P1 variable frequency drives are ideal for fans, pumps, hydraulic pumps, cranes, lifts, injection molding machines, milling machines and winders.
January 2018: The SJ-P1 has replaced the SJ700D series.
Specifications
Alternate Part Number
SJ-P1 Series
Horsepower
40 hp
Housing/Enclosure
IP20 (NEMA 1 Kit Available)
Input Phase
3 Phase
Input Voltage
200-240V, 3 Phase
Outdoor Rated
No
Output
3 Phase Output
Series
SJ P1 Series
Options
Enclosed, Keypad, STO (Safe Torque Off)
STO (Safe Torque Off)
Yes
Torque Load
Variable (VT)
Drives - Type of Drive
Fan and Pump/HVAC
Warranty
1 Year
Weight
49
Series Features Include:
- Heat sink designed for external mounting if required
- RS-485 Modbus RTU standard
- Energy saving function standard
- Keypad /Terminal switching
- Three-wire operation function
- Standard LCD color operator
- PID, Logic and time delay functions built in
- Arithmetic operation and delay functions
- Error codes in text
- Analog input disconnection detect function
- CE/UL/cUL/c-Tick approvals
- 10 year MTBF life design
- Loss of signal protection
- Sink or Source input compatible
- EzCOM for drive to drive master-less communications
- PID Sleep mode function and loss of pressure function
- PMAC motor compatible
