220356
Pepperl+Fuchs

220356

Alt: UB300-18GM40-E4-V1

$252.56

Ultrasonic Sensor, 18mm, Analog Output, 30-300mm Adjustable Range, Straight Head, E4-V1 - PNP, Returns of This Item Must Be Approved by Manufacturer

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Ultrasonic Sesnor, 18mm, Analog Output 30-300mm adj range, Straight Head, E4-V1 - PNP

Features Include:

Sensing Range

  • 35 - 300 mm

Adjustment Range

  • 50 - 300 mm

Dead Band

  • 0 - 35 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 390 kHz

Operating Voltage

  • 10 - 30 V DC , ripple 10 %SS

Input Type

  • 1 program input,
    operating range 1: -UB ... +1 V, operating range 2: +6 V ... +UB
    input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output Type

  • 1 switching output E4, NPN NO/NC, programmable

Rated operating current

  • 200 mA , short-circuit/overload protected

Connection Type

  • Connector M12 x 1 , 4-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
