104095
Alt: UC6000-30GM-IUR2-V15
$696.31
Ultrasonic Sensor, 30mm, Analog Output, 400mm to 6m
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Choose Your Motor Starter Solution
Build your motor starter system with knowledgeable guidance on selecting your components, including starters, contactors, relays, and accessories.
Description
Ultrasonic Sensor, 30mm. Analog Output 400mm to 6m
Specifications
Alternate Part Number
UC6000-30GM-IUR2-V15
Output
Analog Output
Size
30mm
Warranty
18 Months
Series
UC-30GM Series
Weight
1.0000
Features Include:
Sensing Range
- 350 - 6000 mm
Adjustment Range
- 400 - 6000 mm
Dead Band
- 0 - 350 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 65 kHz
Operating Voltage
- 10 - 30 V DC, ripple 10 %SS
Output Type
- 1 current output 4 - 20 mA
- 1 voltage output 0 - 10 V
Connection Type
- Connector M12 x 1, 5-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
