KR50

Features Include:

• Narrow-view and Wide-view types available
• High performance detection of low temperature steel
• Performance comparable to full size HMDs
• Optional airless dust hoods and air purge hoods available
• Type: Narrow view type
• Detection Method: Radiation detection
• Power Supply: 100-110VAC/200-220VAC ±10% ± 50/60Hz
• Power Consumption: 4W or less
• Operation Mode: Light ON
• Detection Object Temperature: 450°C or higher (standard steel material)
• Response Time: 25ms or less
• Indicator: Light reception indicator (red LED)
• Sensitivity Adjustment: Adjustable with volume
• Ambient Humidity: 35-85%RH (non-freezing, non-condensing)
• Insulation Resistance: 500 VDC 20MΩ or more (between primary side of transformer/output terminal and case)
• Dielectric Withstanding: 1.5 kVAC for 1 minute (between primary side of transformer/output terminal and case)
• Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
• Shock: 500 m/s2 / twice each in 3 directions
• Case Material: Aluminum die cast
• Connection: Terminal block (cable opening : Ground hub)

Output Mode:

• Relay output
• Rating: 1c 200 VAC 0.5A or less resistive load

Cooling Water Specification:

• Flow Rate: 2L/minute or more
• Temperature:10°C -35°
• Withstand Voltage: 0.3MPa
