Micron Transformers
B500-0487-8F
Transformer, 500VA, 3.85 Amps, Primary: 208-600V | Secondary:85-130V
$361.50
B500-2008-8F
Alt: ImperviTRAN Series
$259.50
Transformer, 500VA, Primary: 200/208, 220/230/240, 440/460/480VAC, Secondary: 23/110, 24/115, 25/120Vac, 50/60 Hz, Temperature Class 130C, Dual Class CC Primary Fuse Block and Secondary Fuse Clips, UL/cUL, ImperviTRAN Series
- Weight:
- 24.10 LBS
- Minimum Purchase:
- 1 unit
Description
In 1977 Micron introduced the GlobalTRAN line of control transformers, in 1998 they added low voltage general purpose and buck-boost transformers. They have since added DIN rail mount power supplies to their line as well.
Micron is located in Sterling, Illinois and proudly manufacturers in the USA!
Specifications
Alternate Part Number
ImperviTRAN Series
Phase
Single Phase
Primary Voltage
220x440, 230x460, 240x480
Series
ImperviTRAN
Type of Transformer
Control Power
VA
See Spec or N/A
Warranty
3 Years
Weight
24.1
Length/Depth
6.515
Height
7.11
Width
5.25
Features Include:
- Primary Voltage: 200/220/440, 208/230/460, 240/480
- Secondary Voltage: 23/110, 24/115, 25/120
- Rated V.A.: 500
- Rated Frequency: 50/60
- Fusing Capability: Primary & Secondary Fusing
- Fusing Detail: Dual Class CC Primary Fuse Block and Secondary Fuse Clips
- Insulation Class: 130
- Estimated Weight: 23.1 lbs
- Has built in mounting plate for easy install of optional primary fuse block
- Has molded-in terminals and terminal barriers
- Terminals have size #10-32 phillips slotted screws
- Meets UL and cUL
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Micron Transformers
B500-2008-1F
Transformer, 500VA, w/ Secondary Fuse Clip, PRI: 208/230/460V, SEC: 24/115V
$247.50
Micron Transformers
B500-2049-GAF
Transformer, 500VA, 4.35 Amps, Primary: 550/575/600V | Secondary: 110/115/120V
$294.00
$297.75
Micron Transformers
B500-0656-5F
Transformer, 500VA, Primary: 690VAC, Secondary: 120x240VAC, 50/60 Hz, Temperature Class 130C, Removable IP-20 Safetouch™ Covers, ImperviTRAN Series (Please Note 10 Piece Minimum May Be Bypassed By Paying A $100 Set Up Fee, Please Contact Cu
$246.75
Micron Transformers
B500-2286-GAF
Transformer, 500VA, 3.85 Amps, Primary: 208-600V | Secondary:85-130V
$541.50
Micron Transformers
B500-2069-GAF
Transformer, 500VA, 4.55/2.27 Amps, Primary: 380/400/415V | Secondary: 110x220V
$347.25
Micron Transformers
B500-2246-GAF
Transformer, 500VA, 20.8/4.3 Amps, Primary: 230/400/460/575V | Secondary: 24/115V
$540.75
Micron Transformers
B500-2009-GAF
Transformer, 500VA, 4.35 Amps, Primary: 220x440, 230x460, 240x480V | Secondary: 110/115/120V
$276.75
