Micron Transformers
B250-0485-8F
Transformer, 250VA, 1.92 Amps, Primary: 208-600V | Secondary:85-130V
$264.00
B250-2005-8F
Alt: ImperviTRAN Series
$189.75
Transformer, 250VA, Primary: 200/208, 220/230/240, 440/460/480VAC, Secondary: 23/110, 24/115, 25/120Vac, 50/60 Hz, Temperature Class 130C, Dual Class CC Primary Fuse Block and Secondary Fuse Clips, UL/cUL, ImperviTRAN Series
- Weight:
- 12.30 LBS
- Minimum Purchase:
- 1 unit
Description
In 1977 Micron introduced the GlobalTRAN line of control transformers, in 1998 they added low voltage general purpose and buck-boost transformers. They have since added DIN rail mount power supplies to their line as well.
Micron is located in Sterling, Illinois and proudly manufacturers in the USA!
Features Include:
- Primary Voltage: 200/220/440, 208/230/460, 240/480
- Secondary Voltage: 23/110, 24/115, 25/120
- Rated V.A.: 250
- Rated Frequency: 50/60
- Fusing Capability: Primary & Secondary Fusing
- Fusing Detail: Dual Class CC Primary Fuse Block and Secondary Fuse Clips
- Insulation Class: 130
- Estimated Weight: 11.3 lbs
- Has built in mounting plate for easy install of optional primary fuse block
- Has molded-in terminals and terminal barriers
- Terminals have size #10-32 phillips slotted screws
- Meets UL and cUL
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
$177.00
Micron Transformers
B250-0654-5F
Transformer, 250VA, Primary: 690VAC, Secondary: 120x240VAC, 50/60 Hz, Temperature Class 130C, Removable IP-20 Safetouch™ Covers, ImperviTRAN Series (Please Note 10 Piece Minimum May Be Bypassed By Paying A $100 Set Up Fee, Please Contact Cu
$162.00
Micron Transformers
B250-2243-GAF
Transformer, 250VA, 10.4/2.2 Amps, Primary: 230/400/460/575V | Secondary: 24/115V
$383.25
Micron Transformers
B250-2283-GAF
Transformer, 250VA, 1.92 Amps, Primary: 208-600V | Secondary:85-130V
$386.25
Micron Transformers
B250-2016-GAF
Transformer, 250VA, 10.42 Amps, Primary: 240x480V | Secondary: 24V
$251.25
$251.25
Micron Transformers
B250-2263-GAF
Transformer, 250VA, 10.4/2.2/1.1 Amps, Primary: 208/230/400/460/575V | Secondary: 24/115/230V
$411.00
Micron Transformers
B250-2046-GAF
Transformer, 250VA, 2.17 Amps, Primary: 550/575/600V | Secondary: 110/115/120V
$213.00
