80322H6300
Novus

80322H6300

Alt: N322-RHT RS485

$108.00

Temperature/Humidity Controller, RS485, Probe Sensor (Not Included) to Purchase Separately

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Temp/Humidity Controller, Sensor not included, Temperature/Humidity Controller, Need Probe Sensor

Features Include:

  • 3½-digit LED Display
  • Sensor offset adjustment
  • Adjustable hysteresis
  • Configurable setpoint minimum and maximum limits
  • Program retention during power failures
  • Configurable password equipment protection
  • Silicone keys with excellent durability
  • Front-panel with IP65 protection
  • Power supply: 100 to 240 VAC/DC ±10%
  • Frequency: 50~60 Hz
  • Consumption: 5 VA

Dimensions:

  • Humidistat: 75 x 33 x 75 mm
  • Sensor: 125 x 13.7 mm (length x diameter)
  • Sensor cable: 3 meters
  • Panel cutout: 70 x 29 mm

Indication of the selected variable or alternate:

  • One SPDT: 1 HP 250 VAC / 1/3 HP 125 VAC (16 A Resistive) relay output
  • One SPST-NA: 3 A / 250 VCA relay output

Humidity:

  • Measuring range: 0 to 100% of relative humidity (RH)
  • Accuracy for RH: 3% @ 25 °C
  • Measuring resolution: 1% over full range

Temperature:

  • Measuring range: -30 to +105°C (-22 to 221 °F)
  • Accuracy for Temp: 0.5 °C @ 25 °C
  • Resolution: 0.1 °C from19.9 to 199.9 °C
