Alt: Latest Version of PXR3-TAY1-4V0A1
Temp Controller, 1/32 DIN (24x48mm), 100-240VAC, Relay
In 2018 the PXR3 series will switch to Version 2. You will notice a '1' in the part number becoming a '2'.
Our Fuji PXR temperature controllers have auto-tuning and fuzzy controls as well as self-tuning. Self-tuning automatically re-tunes the controller under certain conditions, without the need to revert to auto-tuning.
The screw-terminal on the back eliminates the need for a socket!
Remote monitoring of up to 31 Fuji PXR temperature controllers at a time is possible with the RS485 option that uses the industry-standard Modbus ™ protocol. The communications option comes with our free Windows®-based software, PXR-LITE ™. The software allows you to program the Fuji PXR controller from the PC and view real-time data and trend graph while logging the data on to a text file.
Standard Features Include:
Fuji Temp Controller
Temperature Controller: Input Signal: Thermocouple (°C), Control Output 1: Relay Contact Output, Control Output 2: None, Alarm Options: None, Power Supply: Standard (100-240VAC, 50/60Hz), Additional Functions: RS485 Communication (Modbus),
Fuji Temp Controller
Temperature Controller: Input Signal: 4-20mA DC, 1-5VDC, Control Output 1: Relay Contact Output, Control Output 2: None, Alarm Options: None, Power Supply: Standard (100-240VAC, 50/60Hz), Additional Functions: None , PXR3 Series
Fuji Temp Controller
Temperature Controller: Input Signal: Thermocouple (°C), Control O/P 1: SSR or SSC Drive Output, Control O/P 2: SSR or SSC Drive Output, Alarm Options: None, 100-240VAC, 50/60Hz, Additional Functions: None, PXR3 Series
Fuji Temp Controller
Temperature Controller: Input Signal: RTD, Pt100 Ohm, 3-Wire Type (°F), Control Output 1: 4-20mA DC Output, Control Output 2: SSR or SSC Drive Output, Alarm Options: None, Power Supply: Standard (100-240VAC, 50/60Hz), Additional Functions:
Fuji Temp Controller
Temperature Controller: Input Signal: 0-20mA DC, 0-5VDC, Control Output 1: Relay Contact Output, Control Output 2: None, Alarm Options: None, Power Supply: Standard (100-240VAC, 50/60Hz), Additional Functions: None , PXR3 Series
Fuji Temp Controller
Temp Controller, 1/32 DIN (24x48mm), 100-240VAC, SSR or SSC, 16 Ramp/Soak Segments, Temp/Process
Fuji Temp Controller
Temperature Controller: Input Signal: RTD, Pt100 Ohm, 3-Wire Type (°C), Control Output 1: SSR or SSC Drive Output, Control Output 2: None, Alarm Options: None, 100-240VAC, 50/60Hz, Additional Functions: None, PXR3 Series
