RM1E23AA25
Alt: Minimum Order 5 Pieces, Price per Piece
$112.00
SSR, AS, 230VAC, 4-20mADC, 25A, Solid State Relay, Analog Switching
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 5 units
Specifications
Alternate Part Number
Minimum Order 5 Pieces, Price per Piece
Amp Rating
25 Amp
Control Voltage
4 to 20 mADC
Operating Voltage
230VAC
Output Switching
Analog/Phase Control
Phase
Single Phase
All - Specific Ratings
cULus (CSA/UL)
Series
RM1E Series
Type of Relay
Hockey Puck
Warranty
1 Year
Weight
0.25
Series Features Include:
- AC Solid State Relay
- Analog switching (phase-angle control) for resistive and slightly inductive load applications
- 4 - 20mA or 0 -10V control input
- Rated operational current: 25, 50, 75, 100 and 125 AACrms
- Rated operational voltage: Up to 600 VACrms
- Variable intensity LED-indication according to input current
- Integral snubber network
- Polarized lockable control connector for safe connection for voltage controlled version
