Available Now! RZ3A60A55
Available Now! (3 in stock)
Carlo Gavazzi

RZ3A60A55

Alt: Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 2 Pieces.

$240.80

Solid State Relay, 3 Phase, Zero Switching, 42-660VAC Operational Voltage, 55 Amp, 24-275VAC / 24-50VDC Control Input, 600V Line Voltage, For AC Resistive and Inductive Loads

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added

Have you heard about our rewards program, Pack Perks? Learn all about it here!

Description



Carlo Gavazzi's RZ3A series offers fast electronic switching of 3-phase loads up to 75 amps.

Other features of this contact-free switching line of solid state relays:

  • Zero switching and 4kV isolation
  • Touch protection cover
  • Millions of trouble free operations
  • For AC resistive and inductive load types
  • Available in 25, 55 and 75 amp
  • Line voltage of 400V or 600V
Specifications
Alternate Part Number Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 2 Pieces.
Amp Rating 55 Amp
Control Voltage See Spec
Operating Voltage 600VAC
Output Switching Zero Crossing
Phase Three Phase
All - Specific Ratings See Spec
Series RZ3A Series
Type of Relay Hockey Puck
Quantity 3
Warranty 1 Year
Weight 1

Features Include:

  • 3-phase Solid State Relay
  • Zero switching
  • Rated operational current: 3 x 55 A
  • Rated operational voltage: 42-660 VAC
  • Operational Frequency Range: 45 to 65 Hz
  • Blocking Voltage: 1600 Vp
  • Control voltage: 24-275 VAC / 24-50 VDC
  • Integral snubber network
  • Built-in varistor
  • Over-temperature protection option with alarm output
  • IP10 back-of-hand protection
  • LED indication of control input and over-temperature alarm status
  • Base Plate: aluminum, nickel-plated
Downloads
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Add Selection to Cart

Carlo Gavazzi

RZ3A60A55P

SSR, 3 Pole, Zero Cross, 600VACrms Rated Operational Voltage, 24-275VAC/24-50VDC Control Voltage, 3 X 55AACrms Rated Operational Current, Over-Temperature Protection & Alarm Output, -30 to +80°C (-22 to +176° F), Solid State Relay, IP10
