Dart Controls
253G-200E
DC Speed Control, Input 120/240VAC, Output 0-90/180VDC, 1/8-1hp(90V), 1/4-2hp(180V), Enclosed, NEMA 4/12, 253 Series
$367.20
Available Now!
Available Now!
(1 in stock)
253G-200E-29
Alt: DC Speed Control, Enclosed, NEMA 4/12, 4PDT Center Block
$486.40
DC Speed Control, Input 120/24VAC, Output 0-90/180VDC, 1/8-1hp(90V), 1/4-2hp(180V), Enclosed, NEMA 4/12, -29 is 4PDT Center Block (No Pass) Switch Motor Reversing. Cuts Off Supply Power While Changing Motor Direction, 253 Series
- Weight:
- 2.21 LBS
- Minimum Purchase:
- 1 unit
Description
Our Dart Controls 253G series offers flexibility, reliability, and value.
This general purpose, economical control is rated to 2 horsepower, provides the ultimate in standard features and versatility including:
- Dual voltage (120/240VAC)
- Adjustable H.P. settings
- Packaged power bridge
- Barrier terminal strip
- Fully rated - no auxiliary heatsink required
- Chassis (253G-200C model) or NEMA 4/12 enclosure (253G-200E model).
Input voltage: 12/240 VAC
Output voltage: 0-90/180 VDC
Horsepower range:
- 1/8 to 1hp (90 volt)
- 1/3 to 2 hp (180 volt)
Designed and manufactured right in Indiana!
- Dual voltage - 120/240 VAC, 50/60Hz
- Adjustable horsepower settings
- Barrier terminal strip
- Packaged bridge supply (fullwave)
- 1% speed regulation;
- ±1/2% with tach feedback
- Adjustable Minimum speed
- Adjustable Maximum speed
- Adjustable IR Compensation
- Adjustable Linear Acceleration
- Adjustable Current Limit
- Line voltage compensation
- 5K ohm speed pot, knob and dial included
- Power on/off switch (enclosed models)
- 50:1 speed range
- Overload capacity: 150% for one minute
- Transient voltage protection
- Inhibit circuit
- Enclosed models rated NEMA 4/12
