8824811090
Alt: SSR3-4890 90A / 480 VAC / 3P (Three Phase SSR)
$108.17
Solid State Relay Only, 3-Phase, SSR3-4890, 90 Amp, 480VAC
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Since 1982, NOVUS Automation has manufactured devices for data acquisition, temperature and process control as well as signal conditioning.
NOVUS is headquartered in southern Brazil with sales offices and warehouses in the US as well.
Specifications
Alternate Part Number
SSR3-4890 90A / 480 VAC / 3P (Three Phase SSR)
Amp Rating
90 Amp
Control Voltage
4 to 32VDC
Operating Voltage
530VAC
Output Switching
Zero Crossing
Phase
Three Phase
All - Specific Ratings
See Spec
Type of Relay
Hockey Puck
Warranty
3 Years
Weight
0.25
Features Include:
- Load current (IL): 90 A
- Load voltage: 40 to 530 V rms
- Turn-on voltage (Vssr): < 1.5 V rms
- Leakage current: < 1 mA
- Frequency: 47 to 63 Hz
- dv/dt: 300 V/µs
- Control voltage: 4 to 32 Vcc
- Control current: 15 to 20 mA
- Switching time: < 10 ms
- Control method: Zero cross trigger (resistive load)
- Electrical insulation: > 2000 V rms
- Operating temperature: -40 to 80 °C
- Status Indicator: LED
