RZ3A60D75
Alt: Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 2 Pieces.
$295.20
Solid State Relay, 3 Pole, Zero Switching, 42-660V Operational Voltage, 75 Amp, 4-32VDC Control Input, 600V Line Voltage, For AC Resistive and Inductive Loads
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Carlo Gavazzi's RZ3A series offers fast electronic switching of 3-phase loads up to 75 amps.
Other features of this contact-free switching line of solid state relays:
- Zero switching and 4kV isolation
- Touch protection cover
- Millions of trouble free operations
- For AC resistive and inductive load types
- Available in 25, 55 and 75 amp
- Line voltage of 400V or 600V
Specifications
Amp Rating
75 Amp
Control Voltage
4 to 32VDC
Operating Voltage
600VAC
Output Switching
Zero Crossing
Phase
Three Phase
All - Specific Ratings
See Spec
Series
RZ3A Series
Type of Relay
Hockey Puck
Warranty
1 Year
Alternate Part Number
Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 2 Pieces.
Weight
1
Quantity
2
Features Include:
- 3-phase Solid State Relay
- Zero switching
- Rated operational current: 75 A
- Rated operational voltage: 600 VACrms
- Control voltage, 4-32 VDC
- Integral snubber network
- Built-in varistor
- Over-temperature protection option with alarm output
- IP 10 back-of-hand protection
- LED indication of control input and over-temperature alarm status
