087074

087074

Alt: 87074, NZ2RS-3131-9C-GMMF

$229.09

Single Plunger, NZ2RS-3131-9C-GMMF

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.

Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Features Include:

  • Housing material: Housing Anodized die-cast alloy
  • Ambient temperature: -25 - 80 °C
  • Degree of protection: IP65
  • Mechanical life: 30 x 10^6
  • Contact material: Silver alloy, gold flashed
  • Switching principle: Slow-action switching contact
  • Installation orientation: Any
  • Number of door position positively driven contacts: 2
  • Number of NO contacts: 2
  • Connection: 1 x Plug connector MR9
  • Approach speed: 0.1 - 20 m/min
  • Actuating element: Plain bearing metal Roller plunger
  • Actuating force min.: 15 - 30 N
  • Thermal rated current Ith: 4 A
  • Utilization category acc. to EN 60947-5-1: AC-15 4A 230V | DC-13 4A 24V
  • Short circuit protection according to IEC 60269-1: 4A gG
  • Rated insulation voltage Ui: 250 V
  • Rated impulse withstand voltage Uimp: 2.5 kV
  • Switching current: Min. at DC 24V 1 mA
