134007
Alt: UB6000-F42-E6-V15
$381.36
Ultrasonic Sensor, Top Mount, 400-6000mm Range, 2 Switch Outputs PNP, NO/NC Selectable, V15 5-Pin, Returns of This Item Must Be Approved by Manufacturer
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range 2 switch outputs PNP, NO/NC selectable, V15 5-pin
Features Include:
Sensing Range
- 350 - 6000 mm
Adjustment Range
- 400 - 6000 mm
Dead Band
- 0 - 350 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 65 kHz
Operating Voltage
- 10 - 30 V DC, ripple 10 %SS
Output Type
- 2 switch outputs PNP, NO/NC selectable
Rated operating current
- 200 mA, short-circuit/overload protected
Connection Type
- Connector M12 x 1, 5-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
