111686
Alt: UB5000-F42-UK-V95
$476.95
Ultrasonic Sensor, Top Mount, 400-5000mm Range, 1 Relay Output, NO/NC Selectable, 5-Pin V95 Connector
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Ultrasonic,Top Mount, 400-5000 mm Range 1 relay output, NO/NC selectable, V95 con, 5-pin
Specifications
Alternate Part Number
UB5000-F42-UK-V95
Output
See Spec
Size
See Spec
Warranty
18 Months
Weight
1
Features Include:
Sensing Range
- 350 - 5000 mm
Adjustment Range
- 400 - 5000 mm
Dead Band
- 0 - 350 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 65 kHz
Fusing
- ≤ 3 A Slow-blow fuse in accordance with IEC 60127-2 Sheet 5 required. Recommendation: after a short circuit, check that the device is functioning correctly.
Operating Voltage
- 22 - 253 V DC
Output Type
- 1 relay output
Rated operating current
- 3 A
Connection Type
- 5-pin V95 connector (7/8"-16 UN 2A)
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
