Takex

US-T50

$323.61

Sensor, Ultrasonic, Through Beam, NPN, Red LED, 500mm Range, Cable

SKU:: US-T50
Weight:: 0.25 LBS
Minimum Purchase:: 1 unit

Current Stock:

Quantity:

Current Stock:

Adding to cart… The item has been added

Description
Accessories

Description

Sensor, Ultrasonic, Through Beam, NPN, Red LED, 500mm Range, Cable

Features Include:

Microminiature ultrasonic sensor embedded in a conventional sensor housing
Reliably detecting transparent packaging PET bottle or container
Adjustment POT are equipped on the both model
Detection Method: Through beam
Detection Distance: 500mm or less
Detection Object: 10 x 30mm
Current Consumption: TE50:25mA or less / TD50:15mA or less
Power Supply: 12-24V DC ±10 / Ripple 10± or less
Operation Mode: Detect ON
Operating Angle: 20° (at receiver)
Response Time: 10ms or less
Output Mode: Rating: Sink current 100 mA (30 VDC) or less
Volume (VR): Sensitivity adjustment
Weight: approx. 80g or less

Connection:

Attached cord (dia. 4mm)
Transmitter: 0.2mm2 x 2 cores, 2m
Receiver: 0.2mm2 x 3 cores, 2m

Material:

Case/nut: Heat resistant ABS resin
Detection side: Carbon calcium Silicone-Acrylic coating) conductive EPDM

Indicator:

Red LED: Operation indicator
Green LED: Stability Indicator

Environmental Specifications:

Ambient Temperature:-25° - +55°C (non-freezing)
Ambient Humidity: 35 - 85%RH (non-condensing)
Ambient Wind Speed: 1m/s max.
Vibration: 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
Shock: 500 m/s2 / 3 times each in 3 directions
