Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
Pepperl+Fuchs

233248

Alt: UBE800-F77-SE2-V31

$327.02

Ultrasonic Sensor, Miniature, 1 Switch PNP, NO, Through-Beam, 0...800 mm Emitter/Receiver Spacing

Minimum Purchase:
1 unit
Adding to cart… The item has been added
233248
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
233248
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO
Description
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO Through-beam, 0...800 mm emitter/receiver spacing

Features Include:

Sensing Range

  • 0 - 800 mm emitter/receiver spacing

Transducer Frequency

  • Approximately 300 kHz

Operating Range

  • 20 - 30 V DC , ripple 10 %SS ; 12 - 20 V DC sensitivity reduced to 80 %

Input Type

  • 1 program input (receiver)

Output Type

  • 1 switch output PNP, NO

Rated operating current

  • 200 mA , short-circuit/overload protected

Switching Frequency

  • 100 Hz

Operating Current

  • 0 - 100 mA

Connection Type

  • M8 x 1 connector , 4-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
