233246
Alt: UBR400-F77-E2-V31
$175.08
Ultrasonic Sensor, Miniature, 1 Switch PNP, NO, Reflex, Returns of This Item Must Be Approved by Manufacturer
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Build Your Complete VFD Solution
Create a complete system with recommendations on AC drives and compatible components like motors, circuit breakers, and protection equipment.
Description
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NO Reflex
Specifications
Alternate Part Number
UBR400-F77-E2-V31
Output
See Spec
Series
F77 Series
Size
Flat Pack
Warranty
18 Months
Weight
0.1000
Features Include:
Sensing Range
- 0 - 400 mm
Adjustment Range
- 53 - 400 mm
Standard Target Plate
- 20 mm x 20 mm
Transducer Frequency
- Approximately 300 kHz
Operating Range
- 20 - 30 V DC , ripple 10 %SS ; 12 - 20 V DC sensitivity reduced to 90 %
Input Type
- 1 program input
Output Type
- 1 switch output PNP, NO
Rated operating current
- 200 mA , short-circuit/overload protected
Connection Type
- M8 x 1 connector , 4-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
