Sensor, Ultrasonic, Miniature, 1 Switch PNP, NC
Pepperl+Fuchs

233249

Alt: UBE800-F77-SE3-V31

$327.02

Ultrasonic Sensor, Miniature, 1 Switch PNP, NC, Through-Beam, 0...800 mm Emitter/Receiver Spacing, Returns of This Item Must Be Approved by Manufacturer

Minimum Purchase:
1 unit
Adding to cart… The item has been added
233249
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NC
233249
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NC
Description
Sensor, Ultrasonic, Miniature, 1 Switch PNP, NC Through-beam, 0...800 mm emitter/receiver spacing

Features Include:

Sensing Range

  • 0 - 800 mm emitter/receiver spacing

Transducer Frequency

  • Approximately 300 kHz

Operating Voltage

  • 20 - 30 V DC, ripple 10 %SS; 12 - 20 V DC sensitivity reduced to 80%

Input Type

  • 1 program input (receiver)

Output Type

  • 1 switch output PNP, NC contact

Rated operating current

  • 200 mA, short-circuit/overload protected

Connection Type

  • M8 x 1 connector, 4-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
