$33.00
120343
Alt: UB400-12GM-U-V1
$413.56
Ultrasonic Sensor, Returns of This Item Must Be Approved by Manufacturer
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Ultrasonic
Features Include:
Sensing Range
- 30 - 400 mm
Adjustment Range
- 50 - 400 mm
Dead Band
- 0 - 30 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 310 kHz
Operating Voltage
- 15 - 30 V DC , ripple 10 %SS
Input Type
- 1 program input
lower evaluation limit A1: -UB ... +1 V, upper evaluation limit A2: +4 V ... +UB
input impedance: > 4.7 kΩ, pulse duration: ≥ 1 s
Output Type
- 1 analog output 0 - 10 V
Connection Type
- Connector M12 x 1 , 4-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
Need More Information?
Learn More About Pepperl+Fuchs Here!
