191240

Features Include:

Sensing Range

• 200 - 4000 mm

Adjustment Range

• 240 - 4000 mm

Dead Band

• 0 - 200 mm

Standard Target Plate

• 100 mm x 100 mm

Transducer Frequency

• Approximately 85 kHz

Operating Voltage

• 10 - 30 V DC , ripple 10 %_SS
• 15 - 30 V voltage output

Input/Output Type

• 1 synchronization connection, bidirectional

Output Type

• 1 push-pull (4 in 1) output, short-circuit protected, reverse polarity protected
  Current output 4 mA ... 20 mA or
  voltage output 0 V ... 10 V configurable

Rated operating current

• 200 mA, short-circuit/overload protected


Connection Type

• Connector M12 x 1, 5-pin

Ambient Temperature

• -25 - 70 °C (-13 - 158 °F)

• Pepperl+Fuchs UC4000-30GM-IUEP-IO-V15 Datasheet
• Pepperl+Fuchs Ultrasonic Sensors Catalog
