205346
Pepperl+Fuchs

205346

Alt: UBE1000-18GM40-SE2-V1

$486.01

Ultrasonic Sensor

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Sensor, Ultrasonic

Features Include:

Sensing Range

  • 15 - 1000 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 255 kHz

Operating Voltage

  • 10 - 30 V DC, ripple 10 %SS

Input Type

  • 1 program input
    free air path: -UB ... +1 V, object: +6 V ... +UB
    input impedance: > 4,7 kΩ program pulse: ≥ 1 s

Output Type

  • PNP, NO

Rated operating current

  • 200 mA , short-circuit/overload protected

Connection Type

  • Connector M12 x 1, 4-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
