204531
Pepperl+Fuchs

204531

Alt: UB1000-18GM75-E6-V15

$365.26

Ultrasonic Sensor, Returns of This Item Must Be Approved by Manufacturer

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Sensor, Ultrasonic

Features Include:

Sensing Range

  • 70 - 1000 mm

Adjustment Range

  • 90 - 1000 mm

Dead Band

  • 0 - 70 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 255 kHz

Operating Voltage

  • 10 - 30 V DC, ripple 10 %SS

Input Type

  • 1 program input,
    operating range 1: -UB ... +1 V, operating range 2: +4 V ... +UB
    input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output Type

  • 2 switch outputs PNP, NO/NC, programmable

Rated operating current

  • 2 x 100 mA, short-circuit/overload protected

Connection Type

  • Connector M12 x 1 , 5-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
