102157
Alt: UC500-30GM-E6R2-V15
$508.14
Ultrasonic Sensor, 30mm, 50mm to 500mm Adjustable Range, Dual Switch Point Output, NPN
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Ultrasonic, 30mm, 50mm to 500mm adj range Dual Switch Point Output, NPN
Specifications
Alternate Part Number
UC500-30GM-E6R2-V15
Output
See Spec
Size
30mm
Warranty
18 Months
Series
UC-30GM Series
Weight
0.5000
Features Include:
Sensing Range
- 30 - 500 mm
Adjustment Range
- 50 - 500 mm
Dead Band
- 0 - 30 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 380 kHz
Operating Voltage
- 10 - 30 V DC , ripple 10 %SS
Output Type
- 2 switch outputs PNP, NO/NC, programmable
Rated operating current
- 200 mA, short-circuit/overload protected
Connection Type
- Connector M12 x 1, 5-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
