097974
Pepperl+Fuchs

097974

Alt: UB6000-30GM-E5-V15

$415.57

Ultrasonic Sensor, 30mm, 400mm to 6m Adjustable Range, Single Switch Point Output, PNP, Returns of This Item Must Be Approved by Manufacturer

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Sensor, Ultrasonic, 30mm, 400mm to 6m adj range Single Switch Point Output, PNP

Features Include:

Sensing Range

  • 350 - 6000 mm

Adjustment Range

  • 400 - 6000 mm

Dead Band

  • 0 - 350 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 65 kHz

Operating Voltage

  • 10 - 30 V DC , ripple 10 %SS

Input Type

  • 1 program input,
    operating range 1: -UB ... +1 V, operating range 2: +4 V ... +UB
    input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output Type

  • 1 switch output PNP, Normally open/closed , programmable

Rated operating current

  • 200 mA , short-circuit/overload protected

Connection Type

  • Connector M12 x 1 , 5-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
