102163
Alt: UC6000-30GM-E6R2-V15
$591.66
Ultrasonic Sensor, 30mm, 400mm to 6m Adjustable Range, Dual Switch Point Output, NPN, Returns of This Item Must Be Approved by Manufacturer
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Build Your Complete VFD Solution
Create a complete system with recommendations on AC drives and compatible components like motors, circuit breakers, and protection equipment.
Description
Sensor, Ultrasonic, 30mm, 400mm to 6m adj range Dual Switch Point Output, NPN
Specifications
Alternate Part Number
UC6000-30GM-E6R2-V15
Output
See Spec
Size
30mm
Warranty
18 Months
Series
UC-30GM Series
Weight
1.0000
Features Include:
Sensing Range
- 350 - 6000 mm
Adjustment Range
- 400 - 6000 mm
Dead Band
- 0 - 350 mm
Standard Target Plate
- 100 mm x 100 mm
Transducer Frequency
- Approximately 65 kHz
Operating Voltage
- 10 - 30 V DC, ripple 10 %SS
Output Type
- 2 switch outputs PNP, NO/NC, programmable
Rated operating current
- 200 mA, short-circuit/overload protected
Connection Type
- Connector M12 x 1, 5-pin
Ambient Temperature
- -25 - 70 °C (-13 - 158 °F)
