261242
Alt: UC250-F77-EP-IO-V31, Suggested Alternative to 202070, UB250-F12-EP-V15
$240.49
Ultrasonic Sensor, 10-30VDC, 20-250mm Sensing Range, 4 in1 Switch Point, Adjustment by Pushbutton or IO-Link, M8 Integral (V31 Type), IP67, Smart Sensor
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Easily Find Your Enclosure Solution
Get expert guidance to select the right enclosure and compatible accessories, including subpanels, fans, filters, heaters, thermostats, air conditioning units, and heat exchangers.
Description
The Pepperl+Fuchs UC-77 series are ultrasonic sensors that offer you a flexible solution with a wide range of features and adjustment options.
A few features that stand out:
- Minimal dead band for reliable short-range detection
- Advanced sensor functions ensure complete process reliability
- Quick commissiong with IO-Link integration
- Precise and reliable; high noise immunity
Specifications
Alternate Part Number
UC250-F77-EP-IO-V31, Suggested Alternative to 202070, UB250-F12-EP-V15
Output
See Spec
Series
F77 Series
Size
Rectangular
Warranty
18 Months
Weight
0.1000
Features Include:
- IO-link interface for service and process data
- Programmable via DTM with PACTWARE
- Continuous distance value via IO-Link process data
- Selectable sound lobe width
- Synchronization options
- Temperature compensation
- Push-pull output
