$56.00
BYD50-DDT-T
$56.00
Photoelectric Sensor, Diffuse Reflective, 10-50mm with Timer, 12-24VDC
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Photoelectric, Convergent, 10-50mm, w/ Timer, 12-24VDC
Features Include:
- Sensing type: Convergent reflective type
- Sensing distance: 10 to 50mm
- Sensing target: Opaque, Translucent material
- Light source: Infrared LED
- Response time: Operation: Max. 3ms, Return: Max. 100ms
- Power supply: 12-24VDC ±10%(ripple P-P: max. 10%)
- Current consumption: Max. 35mA
- Operation mode: Light ON
- Control output: NPN open collector
- Connection type: Cable type(Ø3.5, 2m)
- Material Case: Acrylonitrile butadiene styrene, Sensing part: Acrylic, Bracket: Steel Plate Cold Commercial, Bolt: Steel Chromium molybdenum, Nut: Steel Chromium molybdenum, Sleeve: Brass, Ni-plate
