225030

Sensor, Photoelectric, Background Suppression

Features Include:

• Miniature design
• Easy to use
• Very bright, highly visible light spot
• Full metal thread mounting
• Highly visible LEDs for Power ON and switching state
• Not sensitive to ambient light
• Detection range: 5 - 350 mm
• Light type: modulated visible red light
• Diameter of the light spot: Approximately 20 mm at a distance of 350 mm
• Operating voltage: 10 - 30 VDC
• Switching type: The switching type of the sensor is adjustable. The default setting is: light on
• Signal output: 1 PNP output, short-circuit protected, reverse polarity protected, open collector
• Connection: 300 mm fixed cable with 4-pin, M12 x 1 connector
