USA-WG08FS

Sensor, Optional Attachments, Wave Guide, Straight, Use With S1AN

Features Include:

Pipe Length: Pipe can be cut freely on the sensor side

Standard Detection Object: 100X100 mm t = 2 mm aluminum plate

Applicable Sensor: USA-S1AN

Detecting Distance: 100X100 mm t = 2 mm aluminum plate

• 0 - 300mm (with pipe length 100 mm)
• 0 - 200mm (with pipe length 150 mm)
• 0 - 100mm (with pipe length 200 mm)
• (*) Detecting distance depends on the length of pipe.

Materials:

• Pipe: Copper (nickel plated)
• Clamp: Polyacetal resin
• Locking ring: Brass (nickel plated)
