USA-WG08FL

Sensor, Optional Attachments, Wave Guide, Angle, Use With S1AN

Features Include:

Applicable Sensor: USA-S1AN

Standard Detection Object: 100X100 mm t = 2 mm aluminum plate

Pipe Length: Pipe can be cut freely on the sensor side.

Detecting Distance

• 0 - 100mm (with pipe length 100 mm)
• 0 - 75mm (with pipe length 150 mm)
• 0 - 50mm (with pipe length 200 mm)
• (*) Detecting distance depends on the length of pipe.

Materials:

• Pipe: Copper (nickel plated)
• Clamp: Polyacetal resin
• Locking Ring: Brass (nickel plated)
