SS20-T24
$1,734.21
Light Curtain, Thru-Beam, NPN, Infrared LED, Cable, 7m Range, Please Note Takex Has This Item Listed as Non-Cancelable/Non-Returnable.
- Weight:
- 1.76 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Light Curtain, Through Beam, NPN, Infrared LED, Cable, 7000mm Range
Features Include:
- Detection Method: Through beam
- Detection Distance: 7m
- Detection Object: Opaque dia.32mm or more
- Number of Light Axis: 24
- Detecting Width: 460mm
- Optical Axis Interval: 20mm
- Power Supply: 12-24VDC ±10% / Ripple 10% or less
- Output Mode: NPN open collector (*) Rating: Sink current 100mA (30VDC) or less
- Response Time: 15ms or less
- Light source: Infrared LED (wavelength: 950nm)
- Light-Sensitive Element: Photo transistor
- Auxiliary Functions: Output short circuit protection, Anti Interference feature provided for adjacent installation
- Material: Case: aluminum / Front cover, lens: Acrylic
- Connection: Attached cable with connector 0.2m,0.5mm2 x4 cores dia.6.8 mm
- Weight: Approx. 250 - 800g (transmitter/receiver)
Operation Mode:
- A/O operation mode switchable A: ON only when receiving all optical axes (OFF when not receiving even one optical axis)
- O: ON when receiving at least one optical axis (OFF when receiving no optical axis)
Indicator:
- Transmitter: M/S indicator (red LED) / Power indicator (green LED)
- Receiver: Stable light reception indicator (green LED) / Operation indicator (red LED)
Environmental Specifications:
- Ambient Light: 9,000 lx or less
- Ambient Temperature: –10 - +55C° (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 directions
