098314
Alt: KFD2-BR-EX1.3PA.93
$2,708.41
Segment Coupler 1, Output 12.6... 13.4 V, 100mA, Couples PROFIBUS PA Devices Transparently to PROFIBUS DP, Intrinsically Safe, Installation in Zone 2/Class 1, Div. 2, For All Non-Redundant Masters
- Weight:
- 1.25 LBS
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Couples PROFIBUS PA devices transparently to PROFIBUS DP
- Intrinsically safe, Ex ia (FISCO or Entity)
- Installation in Zone 2/Class I, Div. 2
- Fixed, high-availability terminator
- For all non-redundant masters
- Cyclic/acyclic data exchange
- Connection: Power Rail or terminals 59+, 60-, 58 FE
- Rated voltage: 20 - 35 V DC
- Ripple: ≤ 10 %
- Rated current: 190 mA - 430 mA
- Connection terminals: 3, 18+; 2, 17-
- Rated voltage: 12.6 - 13.4 V
- Rated current: max. 100 mA
- Connection type: Terminals
- Core cross-section: up to 2.5 mm2
- Housing: 100 mm x 115 mm x 107 mm
- Degree of protection: IP20
