Wieland is known for their terminal blocks, however, they offer a wide range of automation products as well. This includes circuit protection, heavy duty connectors, programmable safety controllers and safety sensors.
Wieland is a family-owned German manufacturer that was founded in 1910.
Features Include:
Function display: 2 LED, green
Protection degree according to DIN EN 60529 (housing) IP40, (terminals) IP20
Ambient temperature: min. -25 °C, max. 55 °C
Detachable clamps yes
Type of electric connection: screw connection
Model: Basic device
Rated switching voltage, enabling/switching paths AC: 230 V
Rated switching voltage, enabling/switching paths DC: 24 V
Supply Circuit Nominal voltage UN: AC/DC 24 V
Supply Circuit Rated consumption AC: 3.2 VA
Supply Circuit Rated consumption DC: 1.3 W
Dimensions (Depth x Width x Height): 114 mm x 22.5 mm x 96.5 mm
