$3.90
SA2E-TN3-2M
Alt: Replacement for SA1E-TN1, SA1E-TN1-2M, SA1E-TN1-5M, SA1E-TN2, SA1E-TN2-2M and SA1E-TN2-5M
$41.40
Miniature Photoelectric Through-Beam Sensor, 20m Sensing Range, NPN, Light On/Dark On (Selectable), 2m Cable, IP67, 10.8 x 19.5 x 31.5mm (WDH) Excluding LEDs and Controls
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
The SA2E is a miniature high-performance photoeelctric sensor that offers:
- A variety of sensing variations including through-beam, polarized retro-reflective, diffuse reflective, background suppression, small beam
- 0.5ms response time, high speed detection
- BGS - beam diamater has accurate detection of variou objects
- Operating temperatures of -30°C to 55°C
- Ideal for automated parking garage, detecting mirrored surfaces, bathroom sinks, detecting PC boards
The SA2E miniature photoelectric sensors are designed with the same form, fit and functions as the discontinued SA1E series but it comes with MORE!
- Two times faster response time
- Longer sensing distances
- Smaller sensing beam
- Wider operating temperature range
- Selectable light-on/Dark-on operation
- The new SA2E Photoelectric sensors are designed to fit in all existing SA1E applications!
- IDEC discontinued the SA1E series in May 2023
Accessories include reflectors (IAC-Rxx) and cables (SA9Z-xxx).
Specifications
Alternate Part Number
Replacement for SA1E-TN1, SA1E-TN1-2M, SA1E-TN1-5M, SA1E-TN2, SA1E-TN2-2M and SA1E-TN2-5M
Connection
w/Cable
Light Source
LED
NPN or PNP
NPN (Sink)
Light On/Dark On
Light ON/Dark ON
Sensing Method
Through Beam
Type of Photoelectric
General Purpose Photoelectric
All - Specific Ratings
IP67, UL Listed
Series
SA2E Series
Size
Rectangular
Warranty
1 Year
Weight
0.25
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
$3.90
$2.49
