RGC1A60D42KGU
Alt: Minimum Order 5 Pieces, Price per Piece
$103.20
Solid State Relay with Integrated Heat Sink, Zero Cross, 1-Pole Switching, 600VAC, 1200Vp, 43A, 4-32VDC, Screw Connection for Control Terminals, Box Clamp for Power Terminals, SSR Configuration
- Weight:
- 1.14 LBS
- Minimum Purchase:
- 5 units
Description
Carlo Gavazzi is a worldwide leader that designs and manufactures sensors, solid state relays and safety devices as well as monitoring relays, timers and energy management systems.
Carlo Gavazzi was founded in Milan, Italy in 1931 and the U.S. headquarters is located in Buffalo Grove, Illinois.
Features Include:
- Rated operational current @ 40°C: 43 AAC (18000 A²s)
- Control Voltage: 4- 32 VDC
- Rated Voltage: 600 VAC
- Switching Mode: Zero Crossing
- Product Width: 35 mm
- Mounting: DIN rail (panel mount also possible)
- Operational frequency range: 45 to 65 Hz
- Output protection: Integrated varistor
- 100kA short circuit current rating according to UL508
- Conformance to Railway standards
Technical Information:
Read More About Solid State Relays and Carlo Gavazzi Here!
