077805
Alt: 77805, CIT3APL1G05ST
$3,641.55
Reading Station Only, Read-Only Head with Parallel Interface, Plugged in Axially, NUR LESESTATION, CIT3APL1G05ST
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.
Founded by Emil Euchner in 1940, Euchner remains a family owned company.
Features Include:
- Housing material: Plastic
- Ambient temperature: 0 - 50 °C
- Degree of protection: IP65
- Mounting method: Surface
- Connection: M12 plug, 8-pin, axial connection
- Operating voltage: DC 20 - 28 V DC
- Current consumption: 80 - 100 mA Without load
- Switching current: -30 - +30 mA Per output
- Type of output: Push-Pull
- Resistance: 4,5 kΩ Input resistance
- Output voltage: min.Ub - 2 V DC For HIGH level, max.2 V DC For LOW level
- Input voltage: min.15 V DC SKIP input HIGH level, max.2 V DC SKIP input LOW level
- LED indicator: Yellow: Data carrier active
- Data interface: 4 bit binary coded + strobe
