SE-360
$410.50
Quadrature Encoder, Dual Shaft, 360ppr
- Weight:
- 2.00 LBS
- Minimum Purchase:
- 1 unit
Easily Find Your Enclosure Solution
Get expert guidance to select the right enclosure and compatible accessories, including subpanels, fans, filters, heaters, thermostats, air conditioning units, and heat exchangers.
Description
Quadrature Encoder, Dual Shaft, 360ppr
Specifications
Diameter
See Spec or N/A
PPR Pulses Per Revolution
360
Type of Product
See Spec
Warranty
1 Year
Weight
2
Features Include:
High Noise Immunity
Short Circuit Protection
Reverse Polarity Protection
- Inputs: 12 - 28 DCV - 35mA @ 15 DCV typical
- Output: Square wave with 50% duty cycle 0 - 10,000 pulse/sec
- Housing: Rugged anodized aluminum
- Shaft Rotation: Either direction
- Shaft Speed: 6,000 RPM max.
- Shaft: Stainless steel
- Bearings: Heavy duty chrome steel
- Load: 30 lbs. radial: 10 lbs. axial
- Environmental: 32ºF to 149ºF ( 0-65ºC )
Inputs: 12 - 28 DCV - 35mA @ 15 DCV typical
